SK-6 Auto Strong High Precision Self Centering 3 Jaw Lathe Chuck

$760.00
Sold Out

SK-6 High Precision 3 Jaw Self Centering Lathe Chuck – Ø167mm

The SK-6 High Precision 3 Jaw Self Centering Lathe Chuck is a premium-quality chuck engineered for accuracy, durability, and high-speed performance. Manufactured in Taiwan, the SK Series delivers exceptional gripping precision with a total indicated runout (T.I.R) of just 0.03mm, making it ideal for precision machining applications.

Constructed from high-grade Meehanite casting, this chuck provides excellent rigidity and vibration resistance, ensuring stability even at higher spindle speeds.

Key Features

  • 3 Jaw Self Centering Design – Ensures quick setup and accurate workpiece centering.
  • High Precision Accuracy – 0.03mm (0.0012”) T.I.R for reliable machining performance.
  • Ø167mm Chuck Diameter
  • 2-Piece Hardened Jaws – Can be configured for internal or external gripping.
  • Meehanite Casting Body – Provides superior strength, stability, and suitability for high-speed applications.
  • Maximum Speed: 2000 RPM
  • Plain Back Design – Suitable for front or rear back plate mounting.
  • Optional Soft Jaws Available – Bolt-on soft jaws for custom machining applications.

Applications

  • Precision turning operations
  • General engineering and machining
  • CNC and manual lathes
  • High-speed machining environments

Included

  • Chuck Key

Specifications

  • Model: SK-6
  • Type: 3 Jaw Self Centering Lathe Chuck
  • Diameter: 167mm
  • Gripping Accuracy: 0.03mm (0.0012”) T.I.R
  • Body Material: Meehanite Casting
  • Mounting: Plain Back (Front or Rear Back Plate Mount)
  • Max Speed: 2000 RPM
  • Origin: Taiwan

(WTC-AS-SK-6)

SKU WTC-AS-SK-6
Brand Auto Strong
